The Digital gauges simply need a supply voltage in the range of 15 to 48V and then can be directly interrogated via a PC or PLC using either RS232 or RS485 communications.
As these gauges utilise the same technology as their Active counterparts, with the same LED 360° light ring indicator and integrated set-point relay: they are a perfect upgrade for those looking to increase data collection.
We provide digital versions of our APG200, AIM200, and WRG200 ranges, known respectively as: nAPG200, nAIM200, and nWRG200.
Measuring from atmosphere to 1 x 10-9 mbar, and with corrosion resistant/industrial versions, you can select the right gauge for your application.
APG200 Active Pirani Gauge, AIM200LED, WRG200
The Active Pirani Gauge (APG200) is suitable for all vacuum markets, from Analytical instruments who can take advantage of the reduced size and flexible outputs, to Semiconductor for whom the new interfaces and light rings enable better maintenance of systems, to Research and development for whom the local pressure indication helps to monitor experiments away from the main interfaces.
The Active Inverted Magnetron (AIM200) Gauges provide accurate measurement over the vacuum range of 1 x 10-2 to 1 x 10-9 mbar. This gauge is rugged and reliable in a wide range of applications, ranging from scientific instruments to industrial processes.
The AIM200 Gauge is an inverted magnetron gauge head and gauge controller combined into a single compact unit, and features a very low external magnetic field, coupled with an improved striking mechanism makes it ideal for use with sensitive analytical instruments or in applications where the gauge needs to be mounted in close proximity to sensitive equipment.
The Wide Range Gauge (nWRG200) offers the capability of single port pressure measurement in the range atmosphere to 10-9 mbar, with a linear output. It’s a compact solution, halving the space and connectivity hardware requirement, which can be all important in many applications. The nWRG200 has many novel features, including a patented striker, push-button calibration and set-point controls and comprehensive diagnostics. The nWRG200 is a cost-effective vacuum management solution when used either with an Edwards controller or directly integrated into the vacuum system controls.
With every process having a specific requirement, you can see we offer multiple gauge types to make sure you have the right gauge for your need.
From our rugged nAPG200 Pirani gauges, available in standard and corrosion resistant variants, for measuring from atmosphere to 1 x 104 mbar to our nWRG200 Cold Cathode/Pirani combination gauges, to measure from atmosphere down to 1 x 10-9 mbar.
