Extruder Degassing Module

Dry Pumps

The EXDM system is a modular package for recycling and processing plastics. Select the manual or automatic control option for your new or existing installation for flawless performance and higher throughput. With Edwards’ trusted EDC dry claw vacuum pumps at its heart, the EXDM system is designed to tolerate a number of starts and stops without affecting the pump performance or your process.

Simple to operate

The EXDM system easily integrates into your existing system. With easy logic manual and intelligent automatic control options available, the system is robust with customisable filtration and control options.

Kinder on the environment

The proven Edwards dry technology gives you an added advantage. Equipped with a stainless steel claw mechanism and a coated inner chamber housing, the EXDM system does not generate waste water or oil. Your process gets the advantage of a corrosion- free operation.

Built-in solvent flush

You can choose between one or two filters that capture the solids and liquids from the process flow to ensure that the pump runs efficiently. The built-in solvent flush dissolves and removes any condensable build-up.

Not just a pump but also a complete vacuum solution

Complete systemisation available

If your process needs higher capacities or further systemisation that is specific to your process, we are able to offer customised modules and accessories built as per your specifications. This may include multiple pump systems, customised filtration systems and integrated automatic controls.

Global network of application specialists

Seamless selection and installation through our well-placed network of specialists who can help you with process design, systemisation, installation, compliance and after-market.

Wide range of accessories available

Accessories supplied include filters, gauges, gas purges, inlet isolation valves, monitors and controls from gauges to fully enclosed bespoke control units.

Service tailored to your needs

Service includes and is not limited to field service, managed maintenance contracts, vacuum health check, equipment repair routine maintenance and troubleshooting. We guarantee original spare parts, maintenance kits and oil.

Applications

Technical Specifications

Dimensions

Applications

Technical Specifications

	Units	EDC 065 V	EDC 150 V	EDC 300 V
Ultimate pressure	mbar(a)/“HG V/Torr	50/28.4/37.5	50/28.4/37.5	140/25.7/105
Cooling (COOL)		Air Cooled
Supply Voltage	50Hz	200/230/400/500	200/230/400/500	200/230/400/500
	60Hz	200/230/380/460/575	200/230/380/460/575	200/230/380/460/575
	Dual (60Hz only)	Dual voltage 230/460	Dual voltage 230/460	Dual voltage 230/460
Maximum displacement	@50 Hz (m³/h)	67	152	295
Maximum displacement	@60 Hz (m³/h)	81	184	347
Nominal motor power	@50Hz (kW/Hp)	1.8	3.7	6.2
Nominal motor power	@60Hz (kW/Hp)	2.2	4.4	7.5
Mean Sound pressure level	dB(A) 50Hz/60Hz	73.4/76	76/80	80/83
Gear Box Oil Type		ULTRAGRADE KINETIC 150
Permissible ambient temperature range is 0° to 40°C/32° to 104°F. Pumping speed based on air at 20°C/70°F. Tolerance +/- 10%.

Dimensions

	Length		Width		Height		Inlet connection size	Outlet connection size
	mm	in	mm	in	mm	in	BSP*	BSP*
EXDM Series	1650	64.96	1231	48.46	1785	70.27	2″	2″
*Process connections supplied as BSP threads as standard. NPT available on request.
