No moving parts
Radiation tolerant materials in excess of 108 Gray
Up to 250°C and even 450°C
Capture pumps required virtually no maintenance
Low initial and operational costs
capture pumps have no moving parts. Vibration from moving parts and electrical noise is eliminated
capture pumps are built with radiation tolerant materials in excess of 108 Gray. Connectors and cables are also built with radiation tolerant materials for years of continuous operation
without any special consideration, capture pumps can be baked to 250 °C. Removing the magnets allows for hotter bakes up to 450 °C. Long hot bakes are critical to every UHV system
capture pumps require virtually no maintenance and avoid costly vacuum events because they are sealed from atmosphere, saving time, money and resources
initial cost is typically less than comparable specifications of other types of vacuum pumps. They use minimal or no power for years of low cost operation
|
MINI |
3S |
5S |
10S/SW |
10ST |
25S/SW |
25ST |
45S |
75S |
||
|
Pumping speed |
l/s |
0.2 |
2-3 |
4-5 |
8-10 |
8-10 |
15-20 |
15-20 |
30-40 |
40-75 |
|
Ultimate pressure |
mbar |
1×10-11 |
1×10-11 |
1×10-11 |
1×10-11 |
1×10-11 |
1×10-11 |
1×10-11 |
1×10-11 |
1×10-11 |
|
Starting pressure |
mbar |
≤1×10-4 |
≤1×10-4 |
≤1×10-4 |
≤1×10-3 |
≤1×10-3 |
≤1×10-3 |
≤1×10-3 |
≤1×10-3 |
≤1×10-3 |
|
Operating bake temp |
°C |
95 |
450 |
250 |
250 |
80 |
250 |
100 |
250 |
250 |
|
Max. bake temp (Magnets removed) |
°C |
450 |
200 |
450 |
450 |
450 |
450 |
450 |
450 |
450 |
