If you have a harsh general industrial application, the Stokes Microvac remains a perennial favourite. It services a wide range of applications including heat treatment, metallurgy, automotive, PET processing, pharmaceuticals and general applications.
Hermetically sealed, innovative mechanism
Good vacuum level even with Gas Ballast
Simple, easy-to-service mechanism
For "Extended Service Intervals"
With a rotational speed of less than 500 RPM, the Stokes Microvac is 50% slower than competitive models. This means longer life and a greater ability to handle particulate matter from your harsh applications.
The simple mechanism can be easily serviced and maintained on-site. The robust design includes fewer parts that are easily interchangeable, keeping your maintenance and parts costs low.
When you order a Stokes Microvac, our team of highly focused application experts are able to offer you a comprehensive package of design and integrated vacuum system solutions, which can include mechanical booster combinations to meet your specific requirements.
You can choose from a wide range of accessories, including water miser, oil mist separators, gas ballast silencers, auto gas ballast, external oil purifiers, inlet filters and closed loop external cooling systems, providing versatility for numerous applications.
| Pump Type | Maximum pumping speed | Ultimate vacuum | Motor power | Overall dimensions | Noise level 50/60 Hz | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 50 Hz | 60 Hz | L | W | H | ||||||||
| Unit | m3/hr (50 Hz) | cfm (60 Hz) | mbar | Torr | kW | Hp | kW | Hp | in | in | in | dB(A) |
| 212 J | 234 | 138 | <3.3×10-2 | <2.5×10-2 | 5.5 | 7.5 | 5.5 | 7.5 | 26.25 | 24 | 43.5 | <77 |
| 412 J | 442 | 260 | <3.3×10-2 | <2.5×10-2 | 11 | 15 | 7.7 | 10 | 40.25 | 25.63 | 1314 | <85 |
| 612 J | 884 | 520 | <3.3×10-2 | <2.5×10-2 | 11 | 15 | 7.7 | 10 | 43.75 | 70 | 56.63 | <85 |
