Installation is relatively simple with no customer wiring required – they come equipped with an integral IEC connector. The alternate side inlet connection port also allows you to install in height-restricted areas.
The motor is enclosed and cooled by the motor-cooling fan and overheating protection is provided via a thermal overload device. Your EM pump is intelligent too. It automatically resets and restarts the pump when the motor cools down. No manual intervention is required.
| E2M0.7 | E2M1.5 | E1M.18 | E2M18 | E2M28 | ||
| Peak pumping speed | m³/h | 0.75 | 1.6 | 17 | 17 | 27.5 |
| Ultimate vacuum (total pressure) | mbar | 0.03 | 0.03 | 0.03 | 0.001 | 0.001 |
| Ultimate vacuum with gas ballast | mbar | 0.2 | 0.025 | 0.65 | 0.015 | 0.015 |
| Water vapour handling capacity | g/h | 8 | 16 | 650 | 300 | 700 |
| Noise at ultimate | dBA | 43 | 54 | 57 | 57 | 57 |
