TIC turbomolecular pumping stations come in a range of pumping speeds from 85 l/s up to 400 l/s, a TIC controller, and a choice of either oil-sealed or dry backing pump.
All our TIC turbomolecular pumping stations come with nEXT turbomolecular pumps providing proven reliability and end-user serviceability. Oil-sealed pumps come with an EMF mist filter fitted as standard and nXDS dry scroll pumps have an isolation valve fitted between the turbo pump and backing pump as standard.
| Unit | nEXT85 | nEXT85 | nEXT240 | nEXT300 | nEXT400 | |
| Inlet Flange | NW40 | ISO/CF63 | ISO/CF100 | ISO/CF100 | ISO/CF160 | |
| Pumping speed for N2 | l/s | 47 | 84 | 240 | 300 | 400 |
| Compression ration for N2 | >1×1011 | >1×1011 | >1×1011 | >1×1011 | >1×1011 | |
| Backing pump speed 50 Hz (wet) | m³/h | 5 – 12 | 5 – 12 | 5 – 12 | 5 – 12 | 5 – 12 |
| Backing pump speed 50 Hz (dry) | m³/h | 1.2 – 22 | 1.2 – 22 | 6 – 22 | 6 – 22 | 6 – 22 |
| Ultimate vacuum | mbar | <5×10-10 | <5×10-10 | <5×10-10 | <5×10-10 | <5×10-10 |
| Noise level at ultimate | dB(A) | <56 | <56 | <56 | <56 | <56 |
| Controller | TIC | TIC | TIC | TIC | TIC | |
| Backing pump options | nXDS / RV / XDD | nXDS / RV / XDD | nXDS / RV | nXDS / RV | nXDS / RV |
