The first VSD motor with set point control maintains and matches required vacuum levels. The second VSD for the water circulation pump optimises water flow and maintains stable vacuum.
The anti-cavitation algorithm prevents the ELRi from operating in areas of cavitation, which increases the pump lifetime and reduces maintenance costs. The anti- seizure algorithm automatically turns off the pump for a few seconds after long periods of inactivity.
Water spray from the integrated spray nozzles cools and condenses the inlet gas and vapour from the process. This helps reduce energy consumption and increases impeller life.
Remote connectivity via AirLogic® controller and ICON box connectivity makes it easy to identify service requirements and plug gaps.
| Nominal capacity | Ultimate pressure(Absolute) | Nominal installed mototr | Footprint(WxDxH) | Inlet/ Outlet | Connection | Dry weight | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Dry | Saturated | ||||||||||||||
| m³/h | cfm | m³/h | cfm | mbar | inch Hg | kW | hp | mm | inch | Liquid fill / Manual drain | Overflow | Cooler inlet / Outlet | kg | ||
| ELR750i | 740 | 436 | 910 | 536 | 25 | 0.7 | 18.5 | 24.8 | 1950 x 810 x 1020 | 76,8 x 31,9 x 40,2 | EN1092-1/01/B1/DN100/PN10 | G 1/2” BSP(F) | G 1/2” BSP(F) | ISO 228/1-G1” | 820 |
| ELR950i | 940 | 553 | 1090 | 642 | 26 | 34.9 | 885 | ||||||||
| ELR1050i | 1050 | 618 | 1140 | 671 | 37 | 49.6 | 900 | ||||||||
