Dependable new gas system with manual gas ballast control with sleek sheet metal protective enclosure.
In-built off-shelf inverter for simple connection and communication and electrical cabinet designed according to IP54 requirements.
The EXS has a low carbon footprint thanks to its low power and utilities usage. With no contaminated or dirty disposable oil, it is also easy on the environment.
Gain increased productivity with faster processing and pump down times; low ultimate pressures up to < 1 x 10-2.
The EXS pump is suitable for a range of applications in various industries including:
| Specification | Unit | Value | |
|---|---|---|---|
| General | Ultimate Vacuum | Mbar (Torr) | <1 x10-2 (<8×10-3) |
| Peak Pumping Speed | m3/hr (cfm) | 740 (435) | |
Ultimate Power Full Load Power | Kw (hp) | 8 (11) 22 (30) | |
| Maximum Rotor Speed | Rev/min | 7500 | |
| Inlet/Outlet Flange | ISO100/NW50 | ||
| Dimensions (mm) | LxWxH mm (in) | 1650 x 613 x 642 (65 x 24.2 x 25.3) | |
| Cooling | Connection | G1/2” female threads | |
| Cooling Flow (Always On) | l/min (gal/min) | 12 (3.2) | |
| Maximum Supply Pressure | barg (psig) | 7 (100) | |
| Temperature | °C (°F) | 5 to 40 (41 to 104) | |
| Purge | Connection | G1/2” female threads | |
| Pressure | barg (psig) | 3 – 6.9 (43.5 – 100) | |
| Shaft Seal Flow (Always on) | l/min | 12 | |
| Gas Ballast Flow (Manual Adj.) | l/min | 1 – 130 | |
| Operation | Ambient Temperature Range | °C (°F) | 5 to 40 (41 to 104) |
| Noise Level with Silencer | dB(A) | <70 | |
| Maximum Exhaust Back Pressure | bar.a (psig) | 1.2 (2.9) |
